DiaStream® Classic HDF | B. Braun- Home
DiaStream® Classic HDF
7211512DiaStream® Classic HDF
- Produkttyp
- A/V Sets
- Applicable machine
- B.Braun - Dialog
- Features
- Farbkodierte Klemmen, Farbkodierte Patientenklemmen
- Capacity drain bag
- 2 l
- Füllvolumen
- 139 ml
- Inner-ø Pump segment
- 8.00 mm
- Inner-ø Bloodline tubing
- 4,3 mm
- Inner-ø Heparine line
- 1.50 mm
- ø Venous chamber
- 22 mm
- Produkt enthält Latex
- Nein
- Produkt enthält DEHP
- Nein
- Sterilität
- steril
- Sterilisationsart
- Radiation
- Einmalgebr./Wiederverwendbar
- Einwegartikel
- Storage Environment Temperatur
- 0 °C - 30 °C
