Certofix® Duo HF V 715 | B. Braun- Home
Certofix® Duo HF V 715
4168518-07Certofix® Duo HF V 715
- Markenname
- Certofix®
- Produktname (HC)
- Certofix® Duo
- Produkttyp
- Zentraler Venenkatheter
- Einführtechnik
- Seldinger (Seldinger Kanüle)
- Venenzugang
- axillary, subclavia, jugularis
- Kathetermaterial
- PUR
- Anzahl der Lumina
- 2
- French F (Katheter)
- 7.0 Fg
- Katheterlänge
- 15 cm
- Länge (Inch)
- 6"
- Aussen-ø Katheter (metr.)
- 2.40 mm
- Länge des Führungsdrahtes
- 50.0 cm
- Aussen-ø des Führungsdrahts
- 0.890 mm
- mit knickstabil. Führungsdraht
- Ja
- Gauge (distal)
- 14
- Füllvolumen (distal)
- 0.48 ml
- Durchflussrate (distal)
- 105 ml/min
- Gauge (medial 1)
- -
- Gauge (medial 2)
- -
- Gauge (medial 3)
- -
- Gauge (proximal)
- 18
- Füllvolumen (proximal)
- 0.28 ml
- Durchflussrate (proximal)
- 35 ml/min
- Kanülentyp
- Ventilkanüle
- Gauge (Kanüle)
- 18
- Außen-ø Kanüle (mm)
- 1.30 mm
- Kanülenlänge (mm)
- 70 mm
- Länge der Kanüle (inch)
- 2 3/4"
- Aussen-ø Schlauch
- 1.95 mm
- Innen-ø Schlauch
- 1.40 mm
- Schlauchlänge
- 121.50 mm
- EKG-Kabel
- Ja
- beiliegender Konnektor
- Safsite
- mit Skalpell
- Mini
- mit Spritze
- 5 ml
- Art der Verpackung
- Peel pack
- Prod. (unverp.) enthält PVC
- Nein
- Prod. (unverp.) enthält Latex
- Nein
- Prod. (unverp.) enthält DEHP
- Nein
- Produkt enthält PVC
- Ja
- Produkt enthält Latex
- Nein
- Produkt enthält DEHP
- Nein
- Verpackung enthält PVC
- Nein
- Verpackung enthält Latex
- Nein
- Produkt enthält Nickel
- Ja
- Einmalgebr./Wiederverwendbar
- Einwegartikel
- Sterilität
- steril
- Sterilisationsart
- EO
- Antimikrobieller Katheter
- nicht-beschichtet
- High Flow Sets
- Ja
- Safety Sets
- Nein
- Paed Sets
- Nein
