Acculan 4 Stichsäge | B. Braun
- Produkttyp
- Stichsäge
- Markenname
- ACCULAN 4
- Aesculap Produkt Gruppen
- Motorensysteme
- Produktfamilie
- Motoren
- Aussenlänge (mm)
- 212 mm
- Aussenweite (mm)
- 180 mm
- Aussenhöhe (mm)
- 46 mm
- Oszillationsfrequenz (1/min)
- 0 1/min - 15000 1/min
- Antriebsart
- Akku
- Leistung
- 250 W
- Werkzeuganschluss
- Schnellverschluss Stichsäge
- Hub
- 3.2 mm
- Gewicht
- 995 g
- enthaltene Teile
- GA674890, GA678, GB440215
- Artikelnummer ECCOS Halterung
- GB495R
- Disziplin
- Herz-/Thoraxchirurgie, Orthopädie/Traumatologie
- Gefahrgut
- Nein
- UDI-Direktmarkierung
- Ja
- Produkt enthält Latex
- Nein
- Sterilität
- unsteril
- Einmalgebr./Wiederverwendbar
- wiederverwendbar
