LED/Laser Lichtquelle
| B. Braun- Home
LED/Laser Lichtquelle
OP951LED/Laser Lichtquelle
- Produkttyp
- Lichtquelle
- Aesculap Produkt Gruppen
- Endoskopische Technologie
- Produktfamilie
- Gerät
- Type
- Weißlicht und Fluoreszenz
- Breite (mm)
- 330 mm
- Höhe
- 146 mm
- Tiefe (mm)
- 362 mm
- System
- LED-Laser
- Integrierte Ersatzlampe
- Nein
- Lichtintensität regelbar
- Stufenlos
- Automatische Lampenumschaltung
- Kamerakopf
- Stromversorgung
- 100-240 V AC, 50/60Hz
- Max. Stromverbrauch
- 150.0 VA
- Gewicht
- 9 kg
- zu verwenden mit (code)
- PV652, PV651, PV650
- Sterilisationsart
- keine Sterilisation notwendig
- UDI-Direktmarkierung
- Nein
- Schutzklasse gem. EN_60601-1
- CF
- geprüft nach Norm
- EN 60601-1
- Produkt enthält Latex
- Nein
- Sterilität
- unsteril
- Einmalgebr./Wiederverwendbar
- wiederverwendbar
