DiaStream Advanced R | B. BraunRG-60H223DSDiaStream Advanced R
- Produkttyp
- A/V Sets
- Applicable machine
- B.Braun - Dialog, B.Braun - Dialog +, B.Braun - Dialog Advanced
- Features
- Drain Bag 2000 ml, arterielle Kammer, Dorn, Recirculation connector, 3 transducer protectors, Farbkodierte Klemmen
- Capacity drain bag
- 2 l
- Füllvolumen
- 165 ml
- Arterial volume
- 85 ml
- Venous volume
- 80 ml
- Inner-ø Pump segment
- 8.00 mm
- Inner-ø Bloodline tubing
- 4,3/4,8 mm
- Inner-ø Heparine line
- 1.00 mm
- ø Venous chamber
- 22 mm
- Produkt enthält PVC
- Ja
- Produkt enthält Latex
- Nein
- Produkt enthält DEHP
- Nein
- Sterilität
- steril
- Sterilisationsart
- Beta
- Einmalgebr./Wiederverwendbar
- Einwegartikel
- Storage Environment Temperatur
- 5 °C - 35 °C
